High Speed Stacking Door, Fast stacking door,Quick stacking door,
High Speed Stacking Door For YINGLI
The fast stacking door is an upgraded version of the PVC fast rolling shutter door. It is suitable for sizes with a width and height of over 5 meters, designed to meet the demand for high-opening doors and equipped with a certain wind-resistant function when installed outdoors.
| Parameter/Advantage Item | Description and Details |
| Opening Speed | Typically reaches 0.8 – 1.5 m/s, much faster than traditional rolling doors and sliding doors, greatly improving traffic efficiency. |
| Closing Speed | Usually 0.5 – 0.8 m/s, adjustable speed; delayed closing function at the bottom ensures safe passage. |
| Door Material | The curtain is usually made of high-strength PVC polyester fiber base cloth with anti-tear fibers in the middle. |
| Wind Resistance | Uses horizontal wind resistance bars (galvanized round pipes) to divide the curtain into multiple sections, forming an arc wind-resistant structure under wind pressure. |
| Sealing Performance | The door curtain is equipped with dual-side sealing brushes at both sides and a PVC bottom pocket or high-strength sealing rubber strip at the bottom. It fits tightly with uneven ground, effectively preventing dust, low pressure, isolation, and noise. |
| Drive System | Uses high-performance servo motor or frequency conversion motor for smooth start and stop, precise control, low noise, and long service life. |
| Control Method | Supports various automated opening methods such as radar sensor, geomorphic sensor, remote control, pull-rope switch, card swipe, and PLC linkage. |
| Conventional Size | Maximum size: width can exceed 10m, height can exceed 15m, meeting the needs of large openings. |
| Common size: width 5-8m, height 5-8m is the most commonly used. | |
| Operating Temperature | The motor and track system can operate in industrial environments from -30°C to +50°C. Special materials (e.g., low-temperature base cloth) can adapt to more extreme conditions. |
Overview of Quick Stacking Doors
The fast stacking door manufactured by our company is a “wind resistant” high-speed door product independently developed and produced based on the advantages of similar products at home and abroad. Adopting folding high-speed lifting and built-in horizontal wind resistant rod design, the wind pressure can be evenly distributed throughout the door curtain. It has good wind resistance and various advantages of a drum type high-speed rolling door. Suitable for various large-area and large-span buildings, as well as various types of building exterior wall dedicated fast doors that require frequent logistics. Suitable for indoor door openings or large door openings with wind pressure or negative pressure less than 65kg/m2.
Quick stacking door composition
● Door Curtain – The segmented door curtain is made of high-density polyester fiber (with a thickness of 0.9mm), and the transparent window is made of fully transparent PVC film (with a thickness of 1.5mm).
● Door frame structure – The door frame is processed and formed using anti-corrosion galvanized steel plate, with a surface spray treatment, which has a beautiful appearance and is sturdy and durable.
● Drive system – drive specific motor power: 0.75-4kw; Voltage 220V/380V
● Control System – The IP54 control box is compatible with various commonly used protective devices and can be used in conjunction with various door opening systems; The entire system adopts PCL digital programming to achieve safe passage of personnel, vehicles, and items.
Structure
Door Curtain:PVC high-density industrial base fabric configuration with galvanized round pipes
Perspective window: 1.2mm PVC, customizable in height and size
Srevo system: Srevo specific motor power: 0.75-2.2kw: Voltage 220V 50-60Hz
Track and private room: 201 corrosion-resistant stainless steel, beautiful and sturdy
Product Features:
Speed:
The biggest feature of the fast rolling shutter door is equipped with a servo motor, which can open and close stably and quickly.
Safety:
Each door is equipped with infrared photoelectric anti pinch, which can effectively determine whether there are objects or personnel under the door curtain to prevent the door curtain from falling down and injuring people; In addition, safety airbags can be optionally installed, which can be immediately reopened to avoid disrupting the normal operation of the door
Wind Resistance:
The door body of the high-speed folding door adopts a “segmented stacking” structure (unlike the integral rolling of traditional rolling shutter doors). When strong wind acts on the door body, the segmented design can disperse the wind force to multiple stress-bearing units instead of concentrating it on a single roller or track, which greatly reduces the risk of the door body being bent, derailed, or the motor being overloaded. Even in the event of instantaneous strong winds (such as sudden gusts outside a warehouse), the door body can buffer the impact force through its own elastic deformation, avoiding structural damage.
Easy Installation:
Each High Speed Stacking Door of Yingli is made into a module before leaving the factory, including the door body, track, motor and control box, motor compartment, accessories, etc. When you receive the goods, you only need to assemble them together according to the installation video and fix them to the installed door opening. The debugging of the motor provides videos and files for you to view at any time.
In addition, if you encounter any problems that cannot be solved by video and file instructions, please feel free to contact us at any time. We have specialized technology to provide guidance for your door body to ensure that you can install and use it
Frequently Asked Questions
1.Is my venue 6 meters wide and 7 meters high suitable for making quick stacking rolling shutter doors? Do you need customization?
This size is very suitable and needs to be customized, mainly adjusting the length of the door curtain, the height of the track, and the load of the drive system.
2.Can the lifting speed be adjusted? How fast can we get there? Too slow will affect the efficiency of forklift passage
The lifting speed of the fast stacking door is 0.5-1.2m/s, and the speed can be adjusted within a safe range (it needs to be set through the control system and cannot exceed the rated load of the motor). At the same time, it should be reminded that the faster the speed, the better. If the width of the door exceeds 6 meters, it is recommended to reduce the speed appropriately to avoid the door shaking during high-speed operation and balance efficiency and stability.
3.What is the windproof effect? Will outdoor installation be deformed or leak due to strong winds?
This product is an upgraded version of the fast rolling shutter door, specifically designed for outdoor areas with strong winds. The door curtain is embedded with galvanized round pipes to enhance its windproof performance, and the stacked design allows the door to withstand high winds.
